Rice processing precision tester

1. Application

It is used to replace manual visual inspection to objectively, quickly and accurately automatically detect the processing accuracy of rice. After the rice sample to be tested is dyed with a special dye (eosin Y-methylene blue), the skin and embryo on the rice are blue-green, and the endosperm is purple-red. The instrument's dedicated intelligent recognition software automatically analyzes the processing accuracy of the rice sample based on the skin retention on each grain of whole polished rice and its total proportion. The instrument is mainly suitable for scientific research institutes, testing units, rice mills and distribution companies.

2. Main technical indicators

1. The reflective draft scans the dyed rice, and the measurement object is rice (japonica rice, indica rice, glutinous rice).

2. ★The detection method fully complies with relevant national standards such as GB/T 5502-2018 "Grain and Oil Inspection Rice Processing Accuracy Inspection", GB 1354-2018 "Rice", and GB/T5503-2009 "Broken Rice".

3.★ It has 10 standard plates with basically the same size as the long and short axes of rice grains, and provides the standard value of its area Sr.

4.★ It can automatically identify and split rice without special sample arrangement. The sample quantity for a single test is 1-2000 grains (the maximum single test quantity is 18g), and the measurement time is ≤30 seconds. It has the feature of interactive correction and re-judgment by mouse to obtain 100% correct results.

5. Various test reports are directly displayed: skin retention judgment results, skin retention distribution histogram, complete grain classification (whole polished rice rate), broken rice rate. The output data items of the analysis report are optional, and the data can be further statistically analyzed in Excel software.

6. The original image of the test can be saved, and each grain of rice has a separate judgment number. The sample circumscribed rectangle or contour of different test items can be displayed in categories; it has an interface for automatically inputting sample numbers with a barcode gun.

7. It can automatically classify and sort according to the check options of parameters such as "serial number", "skin retention", and "length", and can also output the segmented image by category.

3. Standard configuration

1. 1 set of rice processing precision tester system software USB disk and software lock

2. 1 scanner

Remarks:

1. This product requires a computer, recommended: brand computer (Core i5 9th generation or above CPU/8G memory/wireless network card, 4 or more USB2.0 ports, Windows 10 full professional version or ultimate version).

2. It is recommended to purchase or select dyeing glassware and dyes according to national standards.
