Multifunctional chemiluminescence imaging system

1. Product introduction:

Integrates gel imaging, luminescence imaging, multi-color fluorescence imaging (optional) and other functions. Multi-stage cooling CCD, fast cooling, greatly ensures low dark current under long exposure, equipped with large aperture electric lens, improves imaging sensitivity and quality. A variety of excitation light sources and multi-position filter wheels to meet more experimental needs.

2. Application scope:

1. Nucleic acid detection: various fluorescent dyes, such as Ethidium bromide, SYBR Gold, SYBR Green, GelSafe, GelRed, GelGreen, SYBR Safe, GelStar, Fluorescein, Texas Red, Fluorescein, Oligreen, Picogreen, GelStar labeled DNA/RNA detection.

2. Protein detection: Coomassie brilliant blue gel, silver stain gel, and various dyes Coomassie Blue, Copper stain, Zincstain, Flamingo, Oriole, Silver stain, Coomassie Fluor Orange, SYPROuby, Krypton labeled gel/membrane/chip, etc.

3. Blot membrane detection: Chemiluminescent, ECL, ECL plus, CDP Star, SuperSignal, CSPD, LumiGlo, Cy2, Cy3, Cy5, FITC, Alexa Dyes, DyLight Dyes, ProQ Diamond, ProQ Emerald 300, ProQ Emerald 488, IR Dye 680, etc.

4. Other applications: culture dish colony counting, ELISA plate, dot hybridization, protein chip.

3. Product features:

1. Integrates gel imaging, luminescence imaging, multi-color fluorescence imaging (optional) and other functions.

2. The high-resolution camera combined with a high-sensitivity lens has a strong signal capture capability, and can capture extremely weak signals normally.

3. The body is made of impact-resistant, heat-resistant, and low-temperature-resistant materials, and the drawer-style door design saves space, simplifies the operation steps, and ensures airtightness.

4. Complete Western blot imaging with one click. You can also automatically take 5 or 10 imaging pictures in one click.

5. The body shell is equipped with a glue cutting light source and a one-click shooting button function. You can also switch on and off the glue cutting light source and one-click shooting of luminous imaging normally without operating the software.

4. Technical parameters:

Camera: high-resolution, low-light, high-transparency camera

Camera: deep-cooled scientific research-grade CCD

Effective pixels: 2688×2200 (6 million)

Pixel merging: 1×1, 2×2, 4×4, 6×6, 8×8, 12×12, 16×16

Pixel density: 16bit (65536 grayscale)

Pixel size: 4.54×4.54μm

Photosensitivity: 75%

Dynamic range: 4.6 orders of magnitude

Dark current: <0.0005 e-/pixel/sec. @ -40º C

Cooling temperature: 75℃ below ambient temperature, the software interface can be displayed in real time

Lens: F0.8, High-definition large aperture high-transparency electric zoom lens

Six-position electric filter wheel: standard 590nm, (optional 535nm, 605nm, 700nm, 840nm, etc.)

Transmitted UV: 302nm, using high-efficiency rectifier, rectifier efficiency η: >80%, the average number of lamp switches is up to 40,000 times

Transmitted white light: standard three-color temperature LED uniform light-emitting panel, incident white light: LED white light on both sides

Transmitted blue light: 470m (optional), incident UV: 254nm/365nm (optional)

Ultraviolet Transmission area: 210×260mm, visible light transmission area: 210×260mm, equipped with a special glue cutting device

Computer control: highly programmed, integrated software system, control and parameter setting of the equipment

Timed shutdown: 1-60 minutes without operation to turn off the UV light source, effectively extending the service life of the UV lamp

Structure: airtight without light leakage, microprocessor controlled dark box; automatic door opening protection system to prevent UV damage

5. Intelligent software:

1. Two login modes of the software, password-free login and multi-user password login. Permissions can be set for easy operation and management.

2. Image capture: light source/lens/camera control, automatic/manual exposure, automatic/manual focus, image capture, image management

3. Image processing: adjust brightness, contrast, Gamma, image rotation, image inversion, image cropping, image scaling, image dyeing, image merging

4. Two shooting modes: single and multiple, to meet the usage habits of different users. You can choose whether to shoot the Marker and change the image display format; the multiple mode has automatic (5-shot, 10-shot), manual multiple shooting (unlimited number of shots), and signal accumulation mode shooting.

5. One-click imaging, no need to adjust exposure parameters, simplifying imaging operations; you can frame a specific area, automatically estimate and expose the selected area, and improve the accuracy of automatic exposure.

6. The operating software comes with a direct print window. The grid line function, after selecting, the image interface will appear with evenly arranged green grid lines, and a movable purple horizontal line is specially set. The fixed green frame line and the movable purple line are matched to facilitate reference and comparison of Markers.

7. There is a default image save path, no need to save manually; you can also customize the save path before shooting. The picture taken this time is automatically saved in the selected path. After shooting and exiting the software, the default path will be automatically restored next time to prevent storage confusion

8. Other analysis functions: colony and dot hybridization clone counting.

9. Data export: The results can be exported to Excel.

10. The software can be switched between Chinese and English at will, and the software is upgraded and trained free of charge for life, and the whole machine is guaranteed for three years.
