Portable Ultrasonic Open Channel Flow Meter

1. Product Introduction:

The portable open channel flowmeter is a high-precision measuring instrument designed for hydrological monitoring, river flow monitoring, agricultural irrigation, municipal water supply and drainage and other industries. It uses ultrasonic technology and a special micro-power design scheme, combined with full digital signal processing technology to ensure the stability and reliability of the measurement. The device has a wide measurement range and high measurement accuracy, supports real-time data display, data recording, export and printing, is easy to operate and highly accurate, and is very suitable for occasions that require frequent movement for measurement. At the same time, it is based on the JJG711-1990 verification procedure, and refers to the relevant requirements for flow monitoring units in HJ353-2019, HJ354-2019, HJ355-2019 and HJ15-2019 for comparison and acceptance, ensuring its applicability and accuracy in water conservancy projects, environmental monitoring, agricultural irrigation and other fields.

2. Application scope:

Water conservancy engineering department: monitor the water flow velocity and flow rate of rivers, channels and reservoirs;

Environmental protection departments, water quality monitoring stations and related environmental protection enterprises: use such equipment to monitor the flow rate and flow rate of urban drainage systems and industrial wastewater discharge;

Third-party testing agencies: on-site calibration and comparison of online open channel flowmeter equipment;

Emergency management departments: quickly evaluate water flow conditions and provide data support for flood control and disaster reduction.

3. Implementation standards:

JJG711-1990 "Open channel weir flowmeter";

HJ15-2019 "Technical requirements and detection methods for ultrasonic open channel sewage flowmeter";

HJ353-2019 "Technical specifications for installation of online monitoring systems for water pollution sources (CODCr, NH3-N, etc.)";

HJ354-2019 "Technical specifications for acceptance of online monitoring systems for water pollution sources (CODCr, NH3-N, etc.)";

HJ355-2019 "Technical specifications for operation of online monitoring systems for water pollution sources (CODCr, NH3-N, etc.)";

4. Product features:

1. Applicable to four types of weirs and flumes: triangular weir, rectangular weir, equal width weir and Parshall flume;

2. High-precision signal acquisition module, combined with filtering algorithm, measurement The data is accurate;

3. 7-inch color LCD display, touch-guided operation, and simple operation process;

4. High-performance data processor is used to process data quickly;

5. The curve shows the flow change trend and liquid level change trend;

6. With curve display, the liquid level and flow change trend can be viewed intuitively during measurement;

7. The instrument comes with a micro thermal printer, which can print measurement reports on site;

8. Large-capacity data storage, up to 10,000 historical measurement data can be stored;

9. Data can be directly exported to a USB flash drive, which is convenient for users to perform statistical analysis on the data;

10. Built-in large-capacity lithium battery, which can measure continuously for 48 hours on a single charge;

11. Suitcase design, light weight, convenient for users to carry, waterproof grade IP65.

12. GPS positioning function is standard, and Beidou positioning or other positioning functions can also be customized;

13. It has WIFI connection function and supports remote OTA upgrade program;

14. Power-on password entry effectively protects measurement comparison data and results;

5. Technical parameters

1. Flow measurement range: 0~40m3/s;

2. Liquid level measurement range: 10cm~1m;

3. Flow measurement error: ≤±1%;

4. Liquid level measurement error: ±0.5mm;

5. Built-in battery specifications: 12.6V/4.8Ah, standby time>48 hours;

6. External charger specifications: 12.6V/2A;

7. Data output method: USB;

8. Data printing: built-in thermal printer;

9. Positioning method: standard GPS positioning, Beidou positioning or other positioning functions can be customized;

10. Working environment temperature: -20~50℃

11. Host size: 274*225*113mm;

12. Tripod size: 700*200*130mm;

13. Machine weight: 6.6kg (including tripod, sensor);
