Pesticide and veterinary drug residue rapid detector

Product use of pesticide and veterinary drug residue rapid detector

HED-NS18T pesticide and veterinary drug residue rapid detector is an integrated food safety rapid detection and analysis equipment, widely used in food and drug administration, health departments, colleges and universities, scientific research institutes, agricultural departments, farms, slaughterhouses, food and meat product deep processing enterprises, inspection and quarantine departments and other units.

Application scope of pesticide and veterinary drug residue rapid detector

HED-NS18T pesticide and veterinary drug residue rapid detector can quickly detect pesticide residues in fruits, vegetables and agricultural and sideline products and whether the residues of clenbuterol, antibiotics and veterinary drugs in aquatic products and meat products are qualified on site.

Technical parameters of pesticide and veterinary drug residue rapid detector

1. Android smart operating system, using more efficient and humanized operation, the instrument has wifi network upload, Bluetooth, 4G network transmission, GPRS wireless remote transmission, network cable connection functions, and fast data upload.

2. High degree of intelligence, the instrument has self-test function: it has power-on self-test and zero adjustment functions, and has automatic detection repeatability function.

3. A new generation of high-speed thermal printer, which can automatically print the test report and QR code after the test is completed. Scanning the code with a mobile phone can display detailed test information.

4. The instrument is equipped with a supervision platform, and data can be uploaded to the local area network and the Internet, and the test results are directly transmitted to the food safety supervision platform. Carry out regional food safety supervision and big data analysis and processing and data statistics, detect the long-term and short-term dynamics of regional food safety, and achieve food safety problem estimation and early warning.

5. Detection channel: 18 detection channels, which can test multiple samples at the same time, cycle detection, and release and test at the same time. Each sample is controlled by the program to work independently and will not interfere with each other.

6. Integrated host, including pesticide residue detection module and multi-channel pesticide residue detection module.

7. Integrated portable rapid detection equipment, which meets the needs of on-site and mobile detection, can realize the detection of all detection items under the same software, and can intuitively display the test results through the same window.

8. The instrument has a menu library of various types of samples, which can flexibly select the test samples, and different detection channels can detect different sample items at the same time.

9. Each channel can be closed and opened separately, and the channel properties and sample information in use can be edited.

10. It has a limit query and added substance compliance judgment system. After the detection result is obtained, the system automatically calls the relevant national standards in the system database for comparison and judgment, objectively displays whether the judgment result is qualified, whether the test object is allowed to add the substance, and if it is allowed to add, it can accurately obtain the national standard for the limit of adding the substance to food and the basis for addition.

11. Sample processing is simple and labor-saving, and the overall operation is fast, safe and convenient.

12. The instrument has its own protection function, and the user name and password can be set to prevent non-staff operations.

13. High sensitivity, high detection accuracy, high repeatability accuracy, scanning high-precision optical sensor.

14. Built-in powerful database, you can directly select sample name, detection index, inspection unit and other information on the instrument, or directly edit and enter sample name, detection index, inspection unit and other information on the instrument and save it in the sample database.

15. The instrument has the functions of recalibration, locking, and restoring factory settings.

16. The result judgment line can be modified, the reference value calibration value can be saved, and the data will not be lost when the power is off.

17. The instrument has built-in operation demonstration video, which allows you to learn and operate experiments at the same time.

Main technical indicators of the rapid detector for pesticide and veterinary drug residues

1. The main control chip adopts ARM Cortex-A7, RK3288/4 core processor, with a main frequency of 1.88Ghz, faster operation speed and stronger stability.

2. Display mode: 7-inch LCD touch screen display, humanized Chinese operation interface, intuitive and simple reading.

3. AC and DC dual-use, DC 12V power supply, can be connected to the vehicle power supply, can be equipped with 6ah large-capacity rechargeable lithium battery, convenient for outdoor mobile testing.

4. Four-wavelength cold light source, each channel is equipped with 410, 520, 590, 630nm wavelength light source, standard advanced optical path switching device, optical path switching function can achieve up to 64 wavelengths, and all detection items can achieve simultaneous detection of all channels.

5. Automatic adjustment and calibration of light source brightness.

6. Intelligent constant current voltage regulation, automatic calibration of light intensity, and no temperature drift of light source for long-term continuous operation.

7. Built-in new national limit standards, on-site comparison with the measured results, and continuous updating of standards.

8. Uninterrupted sampling, continuous testing

9. Automatic accumulation of sample numbers.

10. Expandable testing items.

11. Test results can be printed and uploaded in batches.

12. Test results are Excel tables, which can be copied by connecting to a computer.

13. Storage capacity of test results is 200,000

14. Supports U disk storage, standard USB interface, and driver-free installation.

16. Firmware can be upgraded.
