Acid value and peroxide value tester

Product Use

The acid value and peroxide value detector can quickly detect the acid value and peroxide value content in edible vegetable oil, edible lard, peanut oil, sunflower oil, rice bran oil, food, and meat products; through testing, it can be determined whether the vegetable oil meets the national standards or whether it is inferior oil, gutter oil, etc. The instrument reserves other project detection procedures and ports, and can easily add detection items according to future needs.

Instrument Application

The acid value and peroxide value detector is widely used in quality supervision and inspection, industrial and commercial management, fried food production bases, food and drug administration, health departments, meat products and food deep processing enterprises, shopping malls and supermarkets, major food safety monitoring systems and other units.

Function Introduction

1. Android smart operating system, using more efficient and humanized operation, the instrument has network cable connection, wifi network upload, GPRS wireless remote transmission function, and fast data upload.

2. Integrated portable rapid detection equipment, meet the needs of on-site and mobile detection, can realize the detection of all detection items under the same software, and can intuitively display the test results through the same window.

3. High degree of intelligence, the instrument has self-test function: it has power-on self-test and zero adjustment functions, and has automatic detection repeatability function.

4. Detection channel: 12 detection channels, can test multiple samples at the same time, each sample is controlled by the program to work independently, and will not interfere with each other.

5. Equipped with a new generation of embedded thermal printer, you can choose manual printing or automatic printing, and the test report and QR code can be automatically printed after the test is completed.

6. The light source adopts imported ultra-bright light-emitting diodes, which are high-precision, stable, controllable, can turn off unused light sources, and have lower power consumption.

7. It adopts standard USB2.0 interface design, supports U disk storage, driver-free installation, convenient data storage and movement, and can be directly connected to the computer at any time, and the instrument can be controlled by computer. Realize data query, browsing, analysis, statistics, printing, etc.

8. The instrument has a supervision platform. Data can be uploaded to the local area network and the Internet, and the test results can be uploaded directly wirelessly. Perform data analysis and processing, detect the long-term and short-term dynamics of food safety such as oil products, and achieve problem prediction and early warning.

9. The instrument has a menu library of various samples, which can flexibly select test samples, and different test channels can detect different sample items at the same time.

10. Sample processing is simple and labor-saving, and the overall operation is fast, safe and convenient.

11. The instrument has its own protection function, and the user name and password can be set to prevent non-staff operations.

12. High sensitivity, high detection accuracy, high repeatability accuracy, scanning high-precision optical sensor.

13. Built-in powerful database, you can directly select sample name, detection index, inspection unit and other information on the instrument, or directly edit and enter sample name, detection index, inspection unit and other information on the instrument and save it into the sample database.

14. The instrument has the functions of recalibration, locking, and restoring factory settings.

15. The result judgment line can be modified, the reference value calibration value can be saved, and the data will not be lost when the power is off.

Main parameters

1. The main control chip adopts ARM Cortex-A7, RK3288/4 core processor, the main frequency is 1.88Ghz, the operation speed is faster and the stability is stronger.

2. Display mode: 7-inch LCD touch screen display, humanized Chinese operation interface, intuitive and simple reading.

3. DC 12V power supply, can be connected to the vehicle power supply, can be equipped with 6ah large-capacity rechargeable lithium battery, convenient for outdoor flow testing.

4. Automatic adjustment and calibration of light source brightness

5. Intelligent constant current voltage regulation, automatic calibration of light intensity, long-term continuous operation of the light source without temperature drift.

6. Built-in new national limit standards, on-site comparison with the measured results, and continuous update of standards.

7. Uninterrupted sampling, continuous testing

8. Sample numbers are automatically accumulated.

9. The test items can be expanded.

10. The test results can be printed and uploaded in batches.

11. The test results are Excel tables, which can be copied by connecting to a computer.

12. Large-capacity lithium batteries can be configured and the firmware can be upgraded
