Fruit and vegetable respirometer

1. Instrument Use

After harvest, fruit and vegetable products are still an independent organism with life activities. In order to maintain life, they must respire. Respiration is the main physiological metabolism mode of horticultural products such as fruits and vegetables after picking. Respiration intensity is an indicator to measure the strength of respiration. It is an important indicator that must be mastered in studying physiological changes after picking fruits and vegetables and in storage and preservation.

The fruit and vegetable respirometer uses a dual-wavelength infrared carbon dioxide analyzer and a 7-inch Android display. It is specially used for the determination and analysis of the respiration intensity of fruits and vegetables under storage conditions such as normal temperature, cold storage, gas conditioning storage, and supermarket refrigerators.

The characteristics of this instrument are that different volumes of respiration chambers can be selected according to the size of fruits and vegetables, which speeds up the balance and measurement time; the CO2 concentration, O2 concentration, temperature and humidity and change curve of the respiration chamber can be directly displayed.

2. Instrument features

1. Android operating system, more convenient human-computer interaction

2. 7-inch high-definition touch screen, simple operation and clear interface;

3. The gas flow rate is directly set through the instrument, and the respiration intensity of fruits and vegetables under different flow rates can be tested;

4. Special dynamic analysis software can display the experimental process in real time on the Android display, eliminating the need to copy data to the computer for sorting and analysis;

5. The type, name, weight, origin, picking date and other elements of the test fruit or vegetable can be entered;

6. The storage space is 16G, which can store more than 100,000 data;

7. The data can be directly exported to a USB flash drive through the USB interface;

3. Technical indicators

1. Carbon dioxide

Detection principle: non-dispersive infrared method

Sensitivity: Carbon dioxide difference acquisition can be completed within 1 second

Measuring range: 0-5000ppm.

Precision: 3ppm

Resolution: 0.1ppm

2. Oxygen detection

Detection principle: electrochemical formula

Measuring range: 0-100%

Linearity: ≤±2%F.S

Repeatability: ≤±1%

Response time: 30s

Zero drift: ≤±2%F.S/24h

End point drift: ≤±2%F.S/24h

3. Temperature detection

Measuring range: -20-95℃

Resolution: 0.1℃

Precision: ±0.2℃

4. Humidity detection

Measuring range: 0-100%

Resolution: 0.1%

Precision: ±0.2%F.S

5. Power supply voltage: 12V3A power adapter

4. Breathing chamber parameters

1. Net space 80mm with inner diameter 40mm Volume is 0.1 liter

2. Net space 89mm with inner diameter 60mm Volume is 0.25 liter

3. Net space 180mm with inner diameter 120mm Volume is 2 liter

5. Accessories

Name Quantity Unit

Host 1 unit

Breathing chamber 3 sets

Power cord 1 piece

Trachea 2 pieces

Instruction manual 1 copy

U disk 1 piece

Instrument box 1 piece

Packing list 1 copy

Instruction manual 1 copy

Certificate of conformity 1 copy
